In early 1943, the Messerschmitt design bureau were working on an
idea for a single engined, lightweight jet fighter known as the P.1092
series. At the same time, the Argus pulse jet powered Me 328 was also being
developed. Whereas neither of these projects ever reached production (the
328 did make it into prototype testing), the experience gained on them
was utilized on the P.1095 designs. Dipl-Ing Rudolf Seitz led the design
team for the P.1095, and decided to use as many existing components from
other aircraft as possible, to cut down the development and retooling time.
The first P.1095
design of October 1943 was proposed in two versions. One was to use
the entire Me 262 tail unit (horizontal tail and fin/rudder) along with
a wooden wing, the other used the entire Me 328 tail unit (horizontal tail
and fin/rudder) along with a slightly smaller all metal wing. Both
wing version featured leading edge flaps over the entire span. The
two different P.1095 versions used the same fuselage, which included 200
liter (53 gallon) fuel tank between the nose and cockpit, and two 590 liter
(156 gallon) fuel tanks directly aft of the pilot. As with many Messerschmitt
designs, the radio and other equipment was to be placed aft of the rear
fuel tanks ahead of the tail. The powered was provided by a single Jumo
004B jet engine, located below the fuselage. This had the advantage of
being easily serviced, but the drawback of the possibility of the ingestion
of foreign matter into the intake on takeoff. The undercarriage was of
a tricycle design, and the main wheels retracted outwards (600 x 190 mm
tires), and were also taken from the Me 309. A forward retracting nose
gear was located in front of the engine intake (465 x 165 mm tires), and
was tested at the Junkers facilities at Dessau in October 1943 for loss
of thrust caused by the landing gear strut. Two MK 108 30mm cannon were
to be the main armament and were located in the nose.
There was an
additional design from October 19, 1943 for the Me P.1095, which featured
an overall differently shaped aircraft with sligtly swept wings, but not
many details have survived about this version.
The P.1095 project
was discontinued in early 1944, due to the fact that the engine location
was felt to be disadvantageous, and the performance was less than the Me
262 twin jet fighter, which was about to come into service. An interesting
note, the Me 328 was resurrected at this point as a possible "sacrificial"
aircraft, but was not ever used in this role.
Span | Length | Height | Wing Area | Takeoff Weight | Max. Wing Loading | Max. Speed |
9.74 m
31' 11" |
9.71 m
31' 9" |
3.38 m
11' 1" |
15.3 m²
164.7 ft² |
3620 kg
7980 lbs |
237 kg/m²
48.5 lbs/ft² |
860 km/h @ 6000 m
534 mph @ 19685' |
Manufacturer | Scale | Material | Notes |
Planet #017 | 1/72 | Resin & Decals | Solid cast fuselage and engine,
Me 262 tail version |
Me P.1095 design of October 1943 with Me 328 tail | Me P.1095 design of October 19, 1943 |
